Product Name |
MCD6500DSE 6kw Diesel Silent Generator |
MCD8500DSE 6kw Diesel Silent Generator |
Rated Output额定输出(KW) |
6kw |
8kw |
Rated AC Voltage 额定电压 (V) |
110v/220v/380V |
110v/220v/380V |
Frequency 频率(HZ) |
50HZ/60HZ |
50HZ/60HZ |
Engine Speed 转速(R.P.M) |
3000rpm |
3000rpm |
DC Output 直流输出(V/A) |
12v/8.3A |
12v/8.3A |
Starting System 启动系统 |
Auto Start, Recoil Start, Remote Start, Electric Start |
Auto Start, Recoil Start, Remote Start,Electric Start |
Noise Level(dB at 7m)7米处噪音 |
80-85 dB |
80-85 dB |
Continuous Work 持续工作小时(hr) |
13 |
11 |
Engine Type 动力形式 |
Single-cyiinder, vertical,4-stroke air-cooled diesel engine单缸,直立,四冲程,风冷柴油机 |
Single-cyiinder, vertical,4-stroke air-cooled diesel engine单缸,直立,四冲程,风冷柴油机 |
Displacement 排量(cc) |
456cc |
5x75 |
BorexStroke缸径x行程(mm) |
90x75mm |
95x75mm |
Fuel Consumption Rate耗油率(g/kwh) |
295 |
295 |
Fuel Type 燃油 |
0# or -10# light diesel oil 0# 或者-10#清洁柴油 |
0# or -10# light diesel oil 0# 或者-10#清洁柴油 |
Lubrication Oil Volume润滑油容量(L) |
1.65L |
1.65L |
Combustion System 燃烧系统 |
Direct Injection 直喷式 |
Direct Injection 直喷式 |
Standard Features 标准配置 |
Voltmeter, AC Output Socket AC Circuit Breaker, Oil Alert电压表,交流插座,交流断路器,机油报警 |
Voltmeter, AC Output Socket AC Circuit Breaker, Oil Alert电压表,交流插座,交流断路器,机油报警 |
Optional Features 选配 |
Four Sides Wheels, Digital Meter, ATS, Remote Control万向轮，数控表，ATS,遥控启 |
Four Sides Wheels, Digital Meter, ATS, Remote Control万向轮，数控表，ATS,遥控启 |
Gross Weight 毛重 (kgs) |
960*560*780 mm |
960*560*780 mm |
Dimention 包装尺寸(LxWxH)(mm) |
145kg |
150kg |
